Product Parameters
Antenna CategoryDrive AwayAntenna Aperture 0.6mAntenna Type PolarizationLinearFrequency (Rx) 10.70-12.75GHzFrequency (Tx) 13.75-14.50GHzPort isolation (Rx-Tx)Port isolation (Tx-Rx) Gain(Rx)≥34.89+20lg(f/12.50)dBiGain(Tx)≥36.03+20lg(f/14.25)dBiVSWR(Rx)≤1.5:1VSWR(Tx) ≤1.5:1Motion range (AZ) 360° Continuous Unlimited RotationMotion range (EL) 0°~90°Motion range (POL) ±90°AZELPOLInitial acquisition timeInitial Acquisition Time Static:≤80S, Dynamic: ≤120s, Shadowing <10min≤5SBlockage recovery timeInitial Acquisition Time Static:≤80S, Dynamic: ≤120s, Shadowing <10min≤5SPower capacityOperating Temperature-40°C ~ +60 °CStorage Temperature-55°C ~ +70 °CHumidity RequirementOperating wind velocitySurvival wind velocityProtection grade/IP RatingIP65Power supply90~264VAC,47Hz~63Hzpower consumptionMaterialCarbon FiberRemarks
